| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
43511-16G21-000 4351116G21000 4351116G21000 |
BRACKET, FR FOOTREST, R
BRACKET, FRONT FOOTREST RH |
||||
| # 2 |
43521-16G21-000 4352116G21000 4352116G21000 |
BRACKET.FR FOOTREST.L
BRACKET, FRONT FOOTREST LH |
||||
| # 3 |
43571-16G00-000 4357116G00000 4357116G00000 |
PROTECTION
PLATE, BRACKET |
||||
| # 4 |
01550-0820B-000 015500820B000 015500820B000 |
BOLT
BOLT, PLATE
|
||||
| # 5 |
09106-08167-000 0910608167000 0910608167000 |
BOLT, BRACKET
|
||||
| # 6 |
01550-0610B-000 015500610B000 015500610B000 |
BOLT, RH
|
||||
| # 7 |
43530-16G00-000 4353016G00000 4353016G00000 |
HOLDER, FOOTREST RH
|
||||
| # 8 |
09106-10064-000 0910610064000 0910610064000 |
VIS 10MM
BOLT, HOLDER
|
||||
| # 9 |
43510-02F11-000 4351002F11000 4351002F11000 |
BAR, FRONT FOOTREST, R
BAR, FRONT FOOTREST RH
|
||||
| # 10 |
43520-02F11-000 4352002F11000 4352002F11000 |
BAR, FRONT FOOTREST, L
BAR, FRONT FOOTREST LH
|
||||
| # 11 |
09208-08014-000 0920808014000 0920808014000 |
PIN
PIN, RH |
||||
| # 12 |
09208-08016-000 0920808016000 0920808016000 |
PIN
PIN, LH |
||||
| # 13 |
09180-08149-000 0918008149000 0918008149000 |
DOUILLE 8.1X12X22
SPACER
|
||||
| # 14 |
09448-18022-000 0944818022000 0944818022000 |
RESSORT DE REPOSE PIED
SPRING
|
||||
| # 15 |
08332-1106B-000 083321106B000 083321106B000 |
E RING
|
||||
| # 16 |
43576-48B02-000 4357648B02000 4357648B02000 |
BANK SENSOR
BOLT, BANK SENSOR |
||||
| # 17 |
43576-48B20-000 4357648B20000 4357648B20000 |
BOLT, BANK SENSOR, L
BOLT, BANK SENSOR LH |
||||
| # 18 |
43576-48B02-000 4357648B02000 4357648B02000 |
BANK SENSOR
BOLT, BANK SENSOR RH |
||||
| # 19 |
43600-16G30-000 4360016G30000 4360016G30000 |
RH PILLION FOOTREST
FOOTREST ASSY, PILLION RH |
||||
| # 20 |
43700-16G30-000 4370016G30000 4370016G30000 |
LH PILLION FOOTREST ASSY
FOOTREST ASSY, PILLION LH |
||||
| # 21 |
43610-35F00-000 4361035F00000 4361035F00000 |
BAR, PILLION RH
|
||||
| # 22 |
43620-35F00-000 4362035F00000 4362035F00000 |
BAR, PILLION LH
|
||||
| # 23 |
87259-85510-000 8725985510000 8725985510000 |
BOULON REPOSE PIED
PIN
|
||||
| # 24 |
09440-05005-000 0944005005000 0944005005000 |
RESSORT
SPRING
|
||||
| # 25 |
06111-07004-000 0611107004000 0611107004000 |
BALL 7/32 AKS
BALL
|
||||
| # 26 |
43816-33E21-000 4381633E21000 4381633E21000 |
PLATE, PILLION FOOT, R
PLATE, RH
|
||||
| # 27 |
43826-33E22-000 4382633E22000 4382633E22000 |
LH PILLION FOOT PLATE
PLATE, LH
|
||||
| # 28 |
08332-1104B-000 083321104B000 083321104B000 |
E RING
|
||||
| # 29 |
09106-08150-000 0910608150000 0910608150000 |
BOLT
BOLT, BRACKET |
||||
| # 30 |
09164-08020-000 0916408020000 0916408020000 |
RONDELLE 8MM, CONIQUE
WASHER
|
Suzuki SV
Cilinderinhoud: 1000 cc Jaar: 2007 Model code SV1000K7(E2)
