| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
64110-07002-000 6411007002000 6411007002000 |
HUB, WHEEL
|
Niet beschikbaar | |||
| # 1 |
64110-07602-000 6411007602000 |
MOYEU DE ROUE ARRIERE
DISCONTINUED |
Niet beschikbaar | |||
| # 2 |
64210-39100-000 64210-39104-0006421039100000 |
FLASQUE DE FREIN
PANEL |
||||
| # 2 |
64210-39110-000 64210-39115-0006421039110000 |
PANEL, REAR BRAKE ANCHOR
PANEL |
||||
| # 3 |
54410-07002-000 54400-07870-0005441007002000 |
1 PAIRE MACHOIRES DE FREIN ARR
SHOE, BRAKE |
||||
| # 4 |
09443-07001-000 0944307001000 0944307001000 |
RESSORT, MACHOIRES DE FREIN
SPRING
|
||||
| # 5 |
54441-29302-000 54441-29305-0005444129302000 |
CLEF DE FREIN
DISCONTINUED |
||||
| # 6 |
09280-14003-000 09280-14011-0000928014003000 |
JOINT TORIQUE D:2.5, ID: 13.8
O RING |
||||
| # 7 |
09160-14001-000 09160-14055-0000916014001000 |
WASHER, 14.5X22X1.6
WASHER (14.5*22*1.6) |
||||
| # 8 |
64451-48000-000 6445148000000 6445148000000 |
LEVIER DE FREIN ARRIERE
LEVER, BRAKE CAM |
||||
| # 9 |
09100-06078-000 0910006078000 0910006078000 |
VIS 6X33MM
BOLT |
||||
| # 10 |
08322-21068-000 0832221068000 |
WASHER
|
Niet beschikbaar | |||
| # 11 |
08310-11068-000 08310-00067-0000831011068000 |
ECROU 6MM
NUT FIG.42 (H-4) : E16, E18, E22, |
||||
| # 12 |
64611-07000-000 6461107000000 6461107000000 |
SUPPORT DE COURONNE
DRUM, SPROCKET MOUNTING |
||||
| # 13 |
64651-07001-000 6465107001000 6465107001000 |
CAOUTCHOUC AMORTI, COURONNE
SHOCK ABSORBER, HUB
|
||||
| # 14 |
64733-39100-000 6473339100000 6473339100000 |
DOUILLE
RETAINER, MOUNTING
|
||||
| # 15 |
64711-48000-000 64711-48001-0006471148000000 |
AXE DE ROUE ARRIERE GT125E
DISCONTINUED |
||||
| # 16 |
08322-11148-000 08322-01147-0000832211148000 |
WASHER
WASHER, UPPER INNER |
||||
| # 17 |
09180-15042-000 0918015042000 0918015042000 |
DOUILLE 15X28X19
SPACER, LH (15*28*19) |
||||
| # 18 |
09141-14001-000 0914114001000 0914114001000 |
ECROU 14MM
NUT |
||||
| # 20 |
09180-15002-000 0918015002000 0918015002000 |
DOUILLE 15.2X23X33
SPACER, RH (15.2*23*33)
|
||||
| # 21 |
09180-15011-000 0918015011000 0918015011000 |
DOUILLE 15.3X21.7X63
SPACER, HUB BEARING
|
||||
| # 22 |
08144-63027-000 0814463027000 0814463027000 |
ROULEMENT A BILLE
BEARING, RH
|
||||
| # 23 |
08143-62027-000 0814362027000 0814362027000 |
ROULEMENT A BILLE
BEARING, LH
|
||||
| # 24 |
09283-28002-000 09285-28004-0000928328002000 |
OIL SEAL
DISCONTINUED |
||||
| # 25 |
08113-62040-000 09262-20121-0000811362040000 |
ROULEMENT A BILLE 20X47X14
BEARING, RH |
||||
| # 26 |
04111-30308-000 04111-3030A-0000411130308000 |
COTTER PIN
|
||||
| # 27 |
61410-36001-000 61410-36002-0006141036001000 |
TENDEUR DE CHAINE
DISCONTINUED |
||||
| # 28 |
09104-08006-000 09104-08034-0000910408006000 |
BOLT
BOLT (8X50) |
||||
| # 29 |
08310-12088-000 08310-00087-0000831012088000 |
ECROU 8MM
NUT REFER TO FIG.31A(G-3) FOR MODE REFER TO FIG.31B(G-4) FOR MODE |
||||
| # 30 |
64511-20100-000 64511-12B11-0006451120100000 |
SPROCKET, REAR, NT:41
DISCONTINUED |
||||
| # 31 |
09105-08001-000 0910508001000 0910508001000 |
VIS
BOLT
|
||||
| # 32 |
09169-08012-000 0916908012000 0916908012000 |
TOLE DE SURETE
WASHER
|
||||
| # 33 |
08310-12088-000 08310-00087-0000831012088000 |
ECROU 8MM
NUT REFER TO FIG.31A(G-3) FOR MODE REFER TO FIG.31B(G-4) FOR MODE |
||||
| # 34 |
65100-36600-000 6510036600000 6510036600000 |
DISCONTINUED
|
Niet beschikbaar | |||
| # 35 |
55200-11601-000 5520011601000 5520011601000 |
INNER TUBE 300-18
TUBE, INNER (3.00-18) |
Niet beschikbaar | |||
| # 36 |
55261-11010-000 55261-26F10-0005526111010000 |
PROTECTOR, WHEEL INNER TUBE
PROTECTOR (22-18)
|
||||
| # 37 |
65311-20120-000 55311-05300-0006531120120000 |
JANTE 1.60X18
DISCONTINUED |
||||
| # 38 |
65300-20808-000 65320-20120-0006530020808000 |
JEU DE RAYONS
DISCONTINUED |
||||
| # 39 |
55411-11000-000 55411-26G00-0005541111000000 |
BALANCER, WHEEL
BALANCER, WHEEL NO.1 |
||||
| # 40 |
55412-11000-000 55413-41F00-0005541211000000 |
BALANCER
BALANCER, WHEEL NO.2 |
