| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
17661-48G10-000 1766148G10000 1766148G10000 |
COVER, THERMOSTAT
|
||||
| # 2 |
17662-40H00-000 1766240H00000 1766240H00000 |
CONNECTOR, HERMOSTAT INLET
|
||||
| # 3 |
17670-06G50-000 17670-06G51-0001767006G50000 |
THERMOSTAT, WATER
|
||||
| # 4 |
09280-18009-000 0928018009000 0928018009000 |
JOINT TORIQUE D: 3.2, ID: 17.8
O RING
|
||||
| # 5 |
01550-0620A-000 015500620A000 015500620A000 |
BOLT
|
||||
| # 6 |
01547-0625A-000 01547-0625B-000015470625A000 |
BOLT. FINAL GEAR CASE COVER
BOLT |
||||
| # 7 |
17851-40H00-000 1785140H00000 1785140H00000 |
HOSE, RADIATOR INLET
|
||||
| # 8 |
17852-40H00-000 1785240H00000 1785240H00000 |
HOSE, RADIATOR OUTLET
|
||||
| # 9 |
17853-40H00-000 1785340H00000 1785340H00000 |
HOSE, CYLINDER INLET
|
||||
| # 10 |
17854-40H00-000 1785440H00000 1785440H00000 |
HOSE, WATER BYPASS UPPER
|
||||
| # 11 |
17855-40H00-000 1785540H00000 1785540H00000 |
HOSE, WATER BYPASS LOWER
|
||||
| # 12 |
17856-40H00-000 1785640H00000 1785640H00000 |
HOSE, REAR CYL HEAD OUTLET
|
||||
| # 13 |
17857-40H00-000 1785740H00000 1785740H00000 |
HOSE, THERMOSTAT OUTLET
|
||||
| # 14 |
17858-40H00-000 1785840H00000 1785840H00000 |
HOSE, CONDUCTION
|
||||
| # 15 |
17860-40H00-000 1786040H00000 1786040H00000 |
PIPE, CYL WATER INLET
|
||||
| # 16 |
17890-06G20-000 1789006G20000 1789006G20000 |
UNION
|
||||
| # 17 |
17910-40H00-000 1791040H00000 1791040H00000 |
TANK ASSY, RESERVOIR
|
||||
| # 18 |
17931-02FA0-000 1793102FA0000 1793102FA0000 |
CAP, RESERVOIR TANK
CAP
|
||||
| # 19 |
17982-40H00-000 1798240H00000 1798240H00000 |
HOSE, TANK OVERFLOW
|
||||
| # 20 |
17981-40H00-000 1798140H00000 1798140H00000 |
HOSE, TANK INLET NO.1
|
||||
| # 21 |
09352-50901-600 0935250901600 0935250901600 |
HOSE, 5X9X600
HOSE, TANK INLET NO.2
|
||||
| # 22 |
09364-06005-000 0936406005000 0936406005000 |
UNION
JOINT, HOSE
|
||||
| # 23 |
09111-06085-000 0911106085000 0911106085000 |
BOLT
BOLT (6X12) |
||||
| # 24 |
09401-08411-000 0940108411000 |
CLIP
|
Niet beschikbaar | |||
| # 25 |
09401-10411-000 0940110411000 0940110411000 |
CLIP
|
||||
| # 26 |
09407-14403-000 0940714403000 0940714403000 |
GUIDE DE CABLE L=125
CLAMP
|
||||
| # 27 |
09407-19401-000 09407-22403-0000940719401000 |
CLAMP
|
||||
| # 28 |
17730-14G00-000 1773014G00000 1773014G00000 |
BOUCHON LTZ400 K3
CAP |
||||
| # 29 |
17791-14G00-000 1779114G00000 1779114G00000 |
DURITE
CONDUCTION |
||||
| # 30 |
01547-0512A-000 01547-0512B-000015470512A000 |
BOLT. IMMOBILIZER
BOLT |
||||
| # 31 |
17792-40H00-000 1779240H00000 1779240H00000 |
BRACKET
|
||||
| # 32 |
01547-0612A-000 015470612A000 015470612A000 |
BOLT
|
||||
| # 33 |
13650-49X00-000 1365049X00000 1365049X00000 |
SENSOR, WATER TEMP
|
||||
| # 34 |
09168-12017-000 0916812017000 0916812017000 |
BAGUE DE JOINT 12X17X1
GASKET
|
||||
| # 35 |
17891-48G00-000 1789148G00000 1789148G00000 |
JOINT, 3 WAY
|
||||
| # 36 |
09103-06274-000 0910306274000 0910306274000 |
SCREW.6X16
BOLT |
||||
| # 37 |
07130-0612A-000 071300612A000 071300612A000 |
BOLT
|
||||
| # 38 |
09280-18009-000 0928018009000 0928018009000 |
JOINT TORIQUE D: 3.2, ID: 17.8
O RING
|
||||
| # 39 |
09280-26005-000 0928026005000 0928026005000 |
JOINT TORIQUE D: 2.4, ID: 26.2
O RING
|
||||
| # 40 |
09401-12409-000 09401-12414-0000940112409000 |
CLIP
|
||||
| # 41 |
09402-32512-000 0940232512000 0940232512000 |
CLAMP. WATER HOSE
CLAMP |
||||
| # 42 |
09402-38512-000 0940238512000 0940238512000 |
CLAMP
|
||||
| # 43 |
63131-10F00-000 6313110F00000 6313110F00000 |
EMBLEME
TAPE |
