| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
64110-28C01-000 6411028C01000 6411028C01000 |
MOYEU DE ROUE ARRIERE RM250K-M
HUB, REAR |
||||
| # 2 |
64731-00B30-000 6473100B30000 6473100B30000 |
ENTRETOISE ROUE ARR. RM250J-M
SPACER, BEARING |
||||
| # 3 |
08133-62047-000 0813362047000 0813362047000 |
ROULEMENT A BILLE
BEARING
|
||||
| # 4 |
08123-60047-000 08133-60047-0000812360047000 |
ROULEMENT A BILLE
BEARING, REAR HUB, LH |
||||
| # 5 |
08331-41478-000 08331-41479-0000833141478000 |
CIRCLIP
|
||||
| # 6 |
09283-26019-000 0928326019000 0928326019000 |
SIMMER 26X47X5
SEAL, DUST |
||||
| # 7 |
69211-05D00-000 69211-43D00-0006921105D00000 |
DISQUE DE FREIN ARR. RM/N-V
DISC, REAR BRAKE, T:4.5 |
||||
| # 8 |
02122-06167-000 0212206167000 0212206167000 |
VIS M6X16
SCREW
|
||||
| # 9 |
64710-05D00-000 6471005D00000 6471005D00000 |
BROCHE DE ROUE
AXLE, REAR |
Niet beschikbaar | |||
| # 10 |
64741-05D00-000 6474105D00000 6474105D00000 |
DOUILLE, AXE ROUE ARR. DROITE
SPACER, RH |
||||
| # 11 |
64751-05D00-000 6475105D00000 6475105D00000 |
ENTRETOISE
SPACER, LH |
||||
| # 12 |
09160-19010-000 09160-19022-0000916019010000 |
WASHER
|
||||
| # 13 |
08314-41188-000 08314-40187-0000831441188000 |
NUT
NUT 18MM |
||||
| # 14 |
04111-40308-000 04111-4030A-0000411140308000 |
COTTER PIN
PIN, COTTER |
||||
| # 15 |
64511-00B01-000 6451100B01000 6451100B01000 |
COURONNE ARRIERE 520-49
SPROCKET, REAR (NT:49) |
||||
| # 15 |
64511-00B11-000 64511-00B12-0006451100B11000 |
COURONNE ARRIERE 520-50 ACIER
SPROCKET, REAR (NT:50) |
||||
| # 15 |
64511-00B21-000 6451100B21000 6451100B21000 |
COURONNE ARRIERE 520-51
SPROCKET, REAR (NT:51) |
||||
| # 15 |
64511-40261-000 6451140261000 6451140261000 |
COURONNE 520-51 ALUM.
SPROCKET, REAR (NT:51) |
||||
| # 15 |
64511-40271-000 64511-36E00-0006451140271000 |
COURONNE ARR. 520-50 ALUMINIUM
SPROCKET, REAR (NT:50) |
||||
| # 15 |
64511-40281-000 64511-28E00-0006451140281000 |
COURONNE 520-49 ALUMINIUM
SPROCKET, REAR (NT:49) |
||||
| # 16 |
09120-08004-000 0912008004000 0912008004000 |
VIS DE COURONNE 8MM
SCREW |
||||
| # 17 |
09164-08011-000 0916408011000 0916408011000 |
RONDELLE ELASTIQUE
WASHER |
||||
| # 18 |
08319-31087-000 0831931087000 0831931087000 |
ECROU 8MM CHROMEE, AUTOBLOCANTE
NUT
|
||||
| # 19 |
65311-28C00-000 65311-28C01-0006531128C00000 |
RIM, REAR WHEEL 18X2.15, AL
RIM, WHEEL (2.15X18AL) |
||||
| # 20 |
65320-26C00-000 6532026C00000 6532026C00000 |
JEU DES RAYONS ARR. RM250J, K
SPOKE ASSY, WHEEL |
Niet beschikbaar | |||
| # 21 |
69230-05D00-000 6923005D00000 6923005D00000 |
COUVERCLE
COVER, BRAKE DISC |
Niet beschikbaar | |||
| # 22 |
01517-06128-000 01550-06207-0000151706128000 |
VIS 6X20MM, 6-PANS
BOLT, BRACKET REAR |
||||
| # 23 |
61410-05D00-000 6141005D00000 6141005D00000 |
TENDEUR DE CHAINE
ADJUSTER, CHAIN, RH |
Niet beschikbaar | |||
| # 24 |
61420-05D00-000 6142005D00000 6142005D00000 |
TENDEUR DE CHAINE
ADJUSTER, CHAIN, LH |
Niet beschikbaar | |||
| # 25 |
65100-05D10-000 6510005D10000 6510005D10000 |
TIRE, REAR (110/100-18)
|
Niet beschikbaar | |||
| # 26 |
65200-40430-000 6520040430000 6520040430000 |
TUBE, WHEEL INNER
|
Niet beschikbaar | |||
| # 27 |
65261-15010-000 55261-26F10-0006526115010000 |
PROTECTOR, WHEEL INNER TUBE
RR IN TUBE PROTECTOR |
||||
| # 28 |
65270-14200-000 65270-28E00-0006527014200000 |
STOPPER DE PNEU
STOPPER COMP BEAD |
||||
| # 29 |
08322-11088-000 08322-01087-0000832211088000 |
RONDELLE 8MM
.8MM FLAT WASHER, RH |
||||
| # 30 |
08310-12088-000 08310-00087-0000831012088000 |
ECROU 8MM
NUT REFER TO FIG.31A(G-3) FOR MODE REFER TO FIG.31B(G-4) FOR MODE |
||||
| # 31 |
09250-08013-000 0925008013000 0925008013000 |
BOUCHON CAOUTCHOUC
CAP
|
||||
| # 32 |
09813-00039-000 09813-00134-0000981300039000 |
SPANNER
SPANNER, OPEN |
||||
| # 33 |
65271-27C00-000 6527127C00000 6527127C00000 |
CAOUTCHOUC, STOPPER DE PNEU
CUSHION, BEAD STOPPER |
