| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
69600-03E10-000 6960003E10000 6960003E10000 |
MAITRE CYLINDRE
CYLINDER ASSY, REAR |
Niet beschikbaar | |||
| # 2 |
69610-03E00-000 6961003E00000 6961003E00000 |
PISTON DE FREIN
PISTON/CUP SET |
||||
| # 3 |
69691-03E00-000 6969103E00000 6969103E00000 |
CAOUTCHOUC
BOOT |
||||
| # 4 |
69672-03E00-000 6967203E00000 6967203E00000 |
CONNECTEUR
CONNECTOR |
Niet beschikbaar | |||
| # 5 |
D8322-01065-000 08322-0106A-000D832201065000 |
WASHER
|
||||
| # 6 |
D8319-60065-000 D831960065000 D831960065000 |
NUT
|
||||
| # 7 |
D1507-06165-000 D1507-0616B-000D150706165000 |
SCREW. FRONT
BOLT |
||||
| # 8 |
D1507-06255-000 01500-0625B-000D150706255000 |
BOLT
|
||||
| # 9 |
D9500-0093P-000 09401-08401-000D95000093P000 |
BRIDE DE TUYAU
CLAMP |
||||
| # 10 |
69731-03E10-000 6973103E10000 6973103E10000 |
HOSE
HOSE (L:220) |
Niet beschikbaar | |||
| # 11 |
69700-03E00-000 6970003E00000 6970003E00000 |
RESERVOIR
TANK ASSY, REAR RESERVOIR |
||||
| # 12 |
69669-03E00-000 6966903E00000 6966903E00000 |
BOUCHON
CAP |
||||
| # 13 |
69668-03E00-000 6966803E00000 6966803E00000 |
DIAPHRAGME
DIAPHRAGM |
||||
| # 14 |
69667-03E00-000 6966703E00000 6966703E00000 |
TANK
|
||||
| # 15 |
69732-03E10-000 6973203E10000 6973203E10000 |
SPRING
|
Niet beschikbaar | |||
| # 16 |
69480-03E01-000 6948003E01000 6948003E01000 |
DURIT
HOSE, REAR BRAKE |
Niet beschikbaar | |||
| # 17 |
D9500-0093P-000 09401-08401-000D95000093P000 |
BRIDE DE TUYAU
CLAMP |
||||
| # 18 |
37740-03E20-000 3774003E20000 3774003E20000 |
CONTACTEUR
CONTACT |
Niet beschikbaar | |||
| # 19 |
69692-03E00-000 6969203E00000 6969203E00000 |
BIELLETTE
PLATE ASSY |
||||
| # 20 |
69691-03E00-000 6969103E00000 6969103E00000 |
CAOUTCHOUC
YOKE |
||||
| # 21 |
D8310-00065-000 08319-31067-000D831000065000 |
ECROU 6MM CHROMEE
NUT |
||||
| # 22 |
69670-03E00-000 69692-03E00-0006967003E00000 |
BIELLETTE
ROD, PUSH |
||||
| # 23 |
09200-03E00-000 0920003E00000 0920003E00000 |
PIN
|
||||
| # 24 |
D8322-01065-000 08322-0106A-000D832201065000 |
WASHER
|
||||
| # 25 |
D4111-20158-000 04111-2015A-000D411120158000 |
PIN. COTTER
COTTER, PIN |
||||
| # 26 |
59481-00E10-000 5948100E10000 5948100E10000 |
BOLT
|
||||
| # 27 |
59482-00E10-000 5948200E10000 5948200E10000 |
WASHER
|
