| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
21200-31890-000 2120031890000 2120031890000 |
GEAR ASSY, PRIMARY DRIVEN
|
Niet beschikbaar | |||
| # 2 |
09160-25037-000 0916025037000 0916025037000 |
RONDELLE 25.1X54X2.5
WASHER (25.1X54X2.5)
|
||||
| # 2 |
09160-25067-000 09160-25071-0000916025067000 |
WASHER (25X54X2.5)
|
||||
| # 3 |
09263-35017-000 0926335017000 0926335017000 |
ROULEMENT A AIG. 35X40X35.8
BEARING (35X40X35.8)
|
||||
| # 4 |
21410-31E20-000 21410-31E50-0002141031E20000 |
HUB, CLUTCH SLEEVE
|
||||
| # 5 |
21413-31E20-000 2141331E20000 2141331E20000 |
RONDELLE ELASTIQUE D'EMBRAYAGE
SPRING, CLUTCH
|
||||
| # 6 |
21441-31E00-000 2144131E00000 2144131E00000 |
DISQUE D'EMBRAYAGE GARNI (9)
PLATE, CLUTCH DRIVE NO.1
|
||||
| # 6 |
21441-31E30-000 21441-31E50-0002144131E30000 |
PLATE, CLUTCH DRIVE NO.1
|
||||
| # 7 |
21442-31E00-000 2144231E00000 2144231E00000 |
DISQUE D'EMBRAYAGE GARNI (1)
PLATE, CLUTCH DRIVE NO.2
|
||||
| # 8 |
21451-31E00-000 2145131E00000 2145131E00000 |
DISQUE D'EMBRAYAGE METAL.T:1.6
PLATE, CLUTCH DRIVEN NO.1
|
||||
| # 8A |
21451-31E10-000 2145131E10000 2145131E10000 |
DISQUE D'EMBRAYAGE METAL T:2.0
PLATE, CLUTCH DRIVEN NO.2
|
||||
| # 9 |
21462-31E20-000 2146231E20000 2146231E20000 |
PLATEAU PRESSION D'EMBRAYAGE
DISK, CLUTCH PRESSURE
|
||||
| # 10 |
21471-31E20-000 2147131E20000 2147131E20000 |
ANNEAU DE DISQUE EMBRAYAGE
SEAT, CLUTCH PLATE
|
||||
| # 11 |
21472-31E01-000 2147231E01000 2147231E01000 |
WASHER, CLUTCH PLATE WAVE
WASHER, CLUTCH PLATE
|
||||
| # 11 |
21472-31E20-000 2147231E20000 2147231E20000 |
ANNEAU DE DISQUE EMBRAYAGE
WASHER, CLUTCH PLATE
|
Niet beschikbaar | |||
| # 12 |
21611-31E20-000 2161131E20000 2161131E20000 |
GUIDE DE RONDELLE ELASTIQUE
HOLDER, CLUTCH SPRING
|
||||
| # 13 |
21614-31E20-000 2161431E20000 2161431E20000 |
VIS, RONDELLE ELASTIQUE
SCREW, CLUTCH SPRING
|
||||
| # 14 |
21623-31E20-000 2162331E20000 2162331E20000 |
CIRCLIP, RONDELLE ELASTIQUE
SEAT, CLUTCH SPRING
|
||||
| # 15 |
21463-40C01-000 2146340C01000 2146340C01000 |
PIECE DELIER, FLASQUE PRESSION
LIFTER, CLUTCH RELEASE
|
||||
| # 16 |
09159-24010-000 0915924010000 0915924010000 |
ECROU, MOYEU D'EMBRAYAGE
NUT, CLUTCH SLEEVE HUB
|
||||
| # 17 |
08211-25505-000 0821125505000 0821125505000 |
RONDELLE
WASHER, CLUTCH SLEEVE THR
|
||||
| # 17 |
09160-25056-000 0916025056000 0916025056000 |
RONDELLE 25X50X2.5
WASHER, CLUTCH SLEEVE THR
|
||||
| # 18 |
09164-24006-000 0916424006000 0916424006000 |
RONDELLE ELASTIQUE 24.2X35X2
WASHER, CLUTCH WAVE
|
||||
| # 19 |
09381-84002-000 09381-84003-0000938184002000 |
CIRCLIPS
CIRCLIP |
||||
| # 20 |
23110-27A00-000 2311027A00000 2311027A00000 |
TIGE POUSSOIR D'EMBRAYAGE
ROD, CLUTCH PUSH RH
|
||||
| # 21 |
23111-34C00-000 2311134C00000 2311134C00000 |
TIGE POUSSER D'EMBRAYAGE
ROD, CLUTCH PUSH LH
|
||||
| # 22 |
23121-31E00-000 2312131E00000 2312131E00000 |
PIECE DE PRESSION D'EMBRAYAGE
PIECE, CLUTCH PUSH
|
||||
| # 23 |
23200-31300-000 2320031300000 2320031300000 |
MECANISME D'EMBRAYAGE
SCREW ASSY, CLUTCH RELEASE
|
||||
| # 23 |
23200-20C00-000 2320020C00000 2320020C00000 |
MECANISME D'EMBRAYAGE
SCREW ASSY, CLUTCH RELEASE
|
Niet beschikbaar | |||
| # 24 |
09134-06010-000 0913406010000 0913406010000 |
VIS 6X25MM
SCREW (6X25)
|
||||
| # 25 |
08310-00067-000 0831000067000 0831000067000 |
ECROU 6MM
NUT
|
||||
| # 26 |
09160-15045-000 0916015045000 0916015045000 |
RONDELLE 15, 5X28X1
WASHER, CLUTCH PUSH
|
||||
| # 27 |
09263-15003-000 0926315003000 0926315003000 |
ROULEMENT A AIGUILLE 15X28X2
BEARING, CLUTCH PUSH
|
||||
| # 28 |
09285-06015-000 0928506015000 0928506015000 |
SIMMER 6X34X5.5
SEAL, CLUTCH PUSH ROD
|
||||
| # 29 |
09443-09044-000 0944309044000 0944309044000 |
RESSORT
SPRING, CLUTCH RELEASE
|
||||
| # 30 |
01550-06163-000 0155006163000 |
KIT47370-40H00
BOLT, CLUTCH RELEASE |
Niet beschikbaar |
