| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
35601-41G00-000 3560141G00000 3560141G00000 |
LAMP ASSY, FRONT TURNSIGNAL, R
LAMP ASSY, FRONT RH |
||||
| # 2 |
35602-41G00-000 3560241G00000 3560241G00000 |
LAMP ASSY, FRONT TURNSIGNAL, L
LAMP ASSY, FRONT LH |
||||
| # 3 |
35610-41G00-000 3561041G00000 3561041G00000 |
LAMP UNIT. R
LAMP UNIT RH |
||||
| # 4 |
35630-41G00-000 3563041G00000 3563041G00000 |
LAMP UNIT. L
LAMP UNIT LH |
||||
| # 5 |
35618-10G50-000 3561810G50000 3561810G50000 |
RH SOCKET
SOCKET & CORD RH |
||||
| # 6 |
35638-10G50-000 3563810G50000 3563810G50000 |
LH SOCKET
SOCKET & CORD LH |
||||
| # 7 |
09471-12186-000 0947112186000 0947112186000 |
BULB (12V21W)
|
||||
| # 8 |
09132-04032-000 0913204032000 0913204032000 |
SCREW. FR TURNSIGNAL (4X20)
SCREW (4X20) |
||||
| # 9 |
33652-21G10-000 33652-20C00-0003365221G10000 |
CAOUTCHOUC MOUSSE 50X50X5
TAPE, FRONT (40X20X5) |
||||
| # 10 |
94443-21H00-000 9444321H00000 9444321H00000 |
TAPE. FR TURN
CUSHION, FRONT (20X5X0.4) |
||||
| # 11 |
35603-21H00-000 3560321H00000 3560321H00000 |
LAMP ASSY. REAR TURNSIGNAL. R
LAMP ASSY, REAR RH |
||||
| # 12 |
35604-21H00-000 3560421H00000 3560421H00000 |
LAMP ASSY. REAR TURNSIGNAL. L
LAMP ASSY, REAR LH |
||||
| # 13 |
35652-21H00-000 3565221H00000 3565221H00000 |
LENS. R
LENS RH |
||||
| # 14 |
35672-21H00-000 3567221H00000 3567221H00000 |
LENS. L
LENS LH |
||||
| # 15 |
35653-21H00-000 3565321H00000 3565321H00000 |
GASKET
|
||||
| # 16 |
35658-41G00-000 3565841G00000 3565841G00000 |
SOCKET & CORD
SOCKET & CORD RH |
||||
| # 17 |
35678-41G00-000 3567841G00000 3567841G00000 |
SOCKET & CORD
SOCKET & CORD LH |
||||
| # 18 |
35716-07A30-000 3571607A30000 3571607A30000 |
PLATE, REAR COMB
PLATE, REAR |
||||
| # 19 |
09471-12186-000 0947112186000 0947112186000 |
BULB (12V21W)
|
||||
| # 20 |
03211-0412A-000 032110412A000 032110412A000 |
SCREW
|
||||
| # 21 |
03212-04169-000 0321204169000 0321204169000 |
VIS 4X16MM
SCREW
|
||||
| # 22 |
09148-04021-000 0914804021000 0914804021000 |
ECROU
NUT, REAR TURNSIGNAL |
||||
| # 23 |
03541-0412A-000 035410412A000 035410412A000 |
SCREW, REAR
|
||||
| # 24 |
03541-0512A-000 035410512A000 035410512A000 |
--> 03541-0512A-000
SCREW, REAR |
||||
| # 25 |
38610-03F00-000 38610-03F01-0003861003F00000 |
RELAY ASSY. TURNSIGNAL LAMP
RELAY ASSY, TURNSIGNAL
|
||||
| # 26 |
38621-37H00-000 3862137H00000 3862137H00000 |
BRACKET, RELAY
|
||||
| # 27 |
01550-0612A-000 015500612A000 015500612A000 |
BOLT
BOLT, BRKT |
