| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
64100-22850-12Z 641002285012Z 641002285012Z |
WHEEL SET. REAR (16M/CXMT8.00)
WHEEL SET, REAR (16M/CXMT8.00) (SILVER) |
||||
| # 2 |
09319-12019-000 0931912019000 0931912019000 |
DOUILLE
BUSH |
||||
| # 3 |
64731-22H00-000 6473122H00000 6473122H00000 |
SPACER, REAR WHEEL BEARING
|
Niet beschikbaar | |||
| # 4 |
09262-25061-000 0926225061000 0926225061000 |
ROULEMENT A BILLE 25X52X15
BEARING (25X52X15)
|
||||
| # 5 |
08143-62057-000 0814362057000 0814362057000 |
ROULEMENT A BILLE
BEARING |
||||
| # 6 |
09285-32004-000 0928532004000 0928532004000 |
SIMMER 32X52X7, ROUE AVANT
OIL SEAL (32X52X7)
|
||||
| # 7 |
69210-10F40-000 6921010F40000 6921010F40000 |
DISC, REAR BRAKE
|
||||
| # 8 |
09106-08160-000 0910608160000 0910608160000 |
BOLT, DISC
BOLT (8X21) |
||||
| # 9 |
69721-48G20-000 6972148G20000 6972148G20000 |
BRACKET, REAR CALIPER
|
||||
| # 10 |
09103-12109-000 0910312109000 0910312109000 |
BOLT (12X40)
|
||||
| # 11 |
64711-22H00-000 6471122H00000 6471122H00000 |
AXLE, REAR
|
||||
| # 12 |
64741-48G00-000 6474148G00000 6474148G00000 |
SPACER. REAR AXLE. R
SPACER, REAR AXLE RH |
||||
| # 13 |
64772-48G00-000 6477248G00000 6477248G00000 |
SPACER. REAR AXLE. L
SPACER, REAR AXLE LH |
||||
| # 14 |
09159-22007-000 0915922007000 0915922007000 |
NUT.REAR AXLE
NUT |
||||
| # 15 |
09160-22081-000 09160-22081-0000916022081000 |
WASHER. REAR AXLE NUT
WASHER (22X35X2) |
||||
| # 16 |
64680-48G00-000 6468048G00000 6468048G00000 |
JOINT ASSY, REAR HUB
|
||||
| # 17 |
09280-80001-000 0928080001000 0928080001000 |
O RING
O RING (D:2.4, ID:79.8) |
||||
| # 18 |
09119-06049-000 0911906049000 0911906049000 |
VIS 6X16MM
BOLT |
||||
| # 19 |
64679-48G00-000 6467948G00000 6467948G00000 |
WASHER, REAR HUB DRIVEN
|
||||
| # 20 |
64677-48G10-000 6467748G10000 6467748G10000 |
WASHER, THRUST
|
||||
| # 21 |
65110-22H00-000 6511022H00000 6511022H00000 |
TIRE. RR. 240/55R16M/C 86V
TIRE, RR, 240/55R16M/C 86V (BRIDGESTONE) |
||||
| # 22 |
43130-24A00-000 4313024A00000 4313024A00000 |
VALVE, TUBELESS
VALVE ASSY, WHEEL RIM
|
||||
| # 23 |
55411-22H00-000 5541122H00000 5541122H00000 |
BALANCER. WHEEL (NO.1) 0
BALANCER, WHEEL NO.1 |
||||
| # 23 |
55412-22H00-000 5541222H00000 5541222H00000 |
BALANCER. WHEEL (NO.2) 0
BALANCER, WHEEL NO.2 |
||||
| # 23 |
55413-22H00-000 5541322H00000 5541322H00000 |
BALANCER. WHEEL (NO.3) 0
BALANCER, WHEEL NO.3 |
