| Produkt | Onderdeelnummer | Aantal |
|---|
| Produkt | Onderdeelnummer | Aantal |
|---|
| Onderdeelnummer | Produkt | Stukprijs Incl. BTW | Aantal | |||
|---|---|---|---|---|---|---|
| # 1 |
13401-41F20-000 13401-41F22-0001340141F20000 |
BODY, THROTTLE
|
||||
| # 2 |
13565-41F20-000 1356541F20000 1356541F20000 |
PLATE, STAY
|
||||
| # 3 |
13601-21H00-000 1360121H00000 1360121H00000 |
SCREW
|
||||
| # 4 |
13269-18G00-000 1326918G00000 1326918G00000 |
SCREW, AIR ADJ GSX-R1000/K3-
SCREW |
||||
| # 5 |
13271-43E00-000 13271-43E00-0001327143E00000 |
SPRING
|
||||
| # 6 |
13291-26E00-000 1329126E00000 1329126E00000 |
WASHER
|
||||
| # 7 |
13295-26E00-000 1329526E00000 1329526E00000 |
O RING
|
||||
| # 8 |
18117-15H10-000 18117-15H12-0001811715H10000 |
VALVE ASSY, ISC
|
||||
| # 9 |
18119-05H00-000 1811905H00000 1811905H00000 |
O RING
|
||||
| # 10 |
13428-15H00-000 1342815H00000 1342815H00000 |
PLATE. ISC VALVE
PLATE, STAY |
||||
| # 11 |
13605-15H00-000 1360515H00000 1360515H00000 |
SCREW
|
||||
| # 12 |
13580-40F20-000 13580-40F21-0001358040F20000 |
SENSOR ASSY, THROTTLE NO.1
SENSOR ASSY, MAIN |
||||
| # 13 |
13580-41F00-000 13580-41F01-0001358041F00000 |
SENSOR ASSY, SUB
|
||||
| # 14 |
13575-40F00-000 1357540F00000 1357540F00000 |
O RING
|
||||
| # 15 |
13605-40F00-000 1360540F00000 1360540F00000 |
VIS
SCREW |
||||
| # 16 |
09407-14407-000 0940714407000 0940714407000 |
GUIDE DE CABLE L=145
BAND
|
||||
| # 17 |
15710-26GA0-000 1571026GA0000 1571026GA0000 |
INJECTOR ASSY
|
||||
| # 18 |
15721-21H00-000 1572121H00000 1572121H00000 |
O RING
|
||||
| # 19 |
15722-21H00-000 1572221H00000 1572221H00000 |
O RING
|
||||
| # 20 |
13602-34F50-000 1360234F50000 1360234F50000 |
SCREW, THROTTLE COVER
SCREW |
||||
| # 21 |
13473-41FA0-000 1347341FA0000 1347341FA0000 |
PIPE SET, FUEL FR
|
||||
| # 22 |
15721-24F00-000 1572124F00000 1572124F00000 |
O RING
|
||||
| # 23 |
13473-41FB0-000 1347341FB0000 1347341FB0000 |
PIPE SET, FUEL RR
|
||||
| # 24 |
13602-10F10-000 1360210F10000 1360210F10000 |
SCREW
|
||||
| # 25 |
13473-41FC0-000 1347341FC0000 1347341FC0000 |
JOINT
|
||||
| # 26 |
15721-10G00-000 1572110G00000 1572110G00000 |
O RING
|
||||
| # 27 |
13474-41F20-000 1347441F20000 1347441F20000 |
PLUG, STRAIGHT
|
||||
| # 28 |
15721-41F20-000 1572141F20000 1572141F20000 |
O RING
|
||||
| # 29 |
13475-41F20-000 1347541F20000 1347541F20000 |
PLATE
|
||||
| # 30 |
13683-41FA0-000 1368341FA0000 1368341FA0000 |
HOSE
|
||||
| # 31 |
13683-41FD0-000 1368341FD0000 1368341FD0000 |
TUBE, RUBBER
|
||||
| # 32 |
18591-42F00-000 1859142F00000 1859142F00000 |
SENSOR, PRESSURE
|
||||
| # 33 |
18595-42F20-000 1859542F20000 1859542F20000 |
HOLDER
|
||||
| # 34 |
18598-41F00-000 1859841F00000 1859841F00000 |
BRACKET
BRACKET, BOOST SENSOR FR |
||||
| # 35 |
18599-39G00-000 1859939G00000 1859939G00000 |
BRACKET
BRACKET, BOOST SENSOR RR |
